Type:                                  Trimaran, Sail, Center cockpit
Rig:                                     Two-masted staysail schooner
Hull No.:                             MCZ 171150796 (US Coast Guard)
Harbor:                               Ann Arbor, Michigan, USA
Designer/builder:                  F. Slintak

LOA (length overall):           65 ft. 2 in.
LOD (length on deck):         52 ft.
Beam (hull):                         15.5 ft.
Beam (ovrall):                      29 ft.
Sail area:                             1,530 ft. sq.
Displacement:                      36,000 lb
Ballast:                                 None

Motor:                                 50 HP Volvo Diesel
Sails:                                    8 (5 regular, 3 storm)
Anchors:                              3 (65 lb., 45 lb., 35 lb.)
Anchor windlass:                  12 V, 500 lb. load
Rigging:                                3/8 in. galvanized, spliced eyes
Furling gear:                         2 (staysail, jib)
Fuel/water tanks:                  75 gal. (Diesel fuel), 150 gal. (water)
Electric gen.:                        4.0 kW Apollo Diesel, 110 V A.C.
                                            350 Watt Air Marine wind turbine
Batteries:                              3 (220 Amp. hrs., 350 Ah, 65 Ah)
Bilge pumps:                         3 (12 V electr. automatic, 2 manual)
Dinghy:                                 11.0 ft. + 5.0 HP Nissan engine
Elektronics:                           2 VHF marine radios
                                            3 GPS radios (radios for marine navigation)
                                            100 W ham radio transceiver
                                            EPIRB (marine safety automatic transmitter )
                                            Depth, wind spead and wind direction indicators
                                            14 in. TV/VCR combo
                                            AM/FM, tape, CD player
Cabin heating:                       Dickinson Diesel fuel space heater
                                            1.5 kW AC space heater
Misc. equipment:                  4-burner LPG stove/oven
                                            PH-II Raritan head
                                            10 ga. water heater/shower
                                            12 V ice box/refrigerator
                                            2-burner LPG barbecue
